Air-cooled Spindle Motor Air Cooled 65mm ER11 220V 1500W CNC Spindle With 4 x Bearing 0.8KW/1.5KW2.2KW/3KW ER11/ER20 80mm/100mm

Spindle Features :

100% Brand New






Speed:0-24000 R/min

Air Cooling ER11 collet /ER20 collets chuck


Runout off: less than 0.02mm

Bearing:With 4pcs Bearing

Grease Lubrication


Material: Stainless Steel

Size: Φ 65mm/80mm/100mm/105mm

Power: 0.8KW/1.5KW2.2KW/3KW

Voltage: 220VAC

Current: 8A

Frequency: 0-400Hz

Speed: 10-24000rpm

Cooling: Air-cooled

Accuracy: 0.003--0.005

Runout off: Less than 0.05mm

Bearing Lubrication: Grease

Collet size: ER16 3.175 mm,4mm ,6 mm,8mm,10mm(one spindle with 2 collet)

Bearings: 4 bearings(C7004x2 + C7002x2),P4 class, Angular contact bearings

Weight: About 3.5kg

Suitable for wooden carving , drilling , engraving and milling machinery

Package Content: 1 x Air-cooled Spindle Motor (type as you choose)


Brand Name ICROATO
Type ER11 1.5kw spindle
Operating Speed 24000RPM
Certification CE
Drive Motor
Application Milling
Feature 1 spindle 800w
Maximum Torque 0
Origin CN(Origin)
Diameter 65mm
Feature 2 lathe spindle
Feature er11 spindle motor
Feature 3 spindel motor cnc
Feature 4 spindle 2 2kw
Feature 5 cnc spindle motor
Bearing type C7004x2
Feature 6 er20 motor dc
Model Number 0.8kw/1.5kw/2.2kw/3kw air-cooled spindle
Feature 7 spindel cnc
Feature 8 air cooling spindle
Feature 9 spindle 1.5
Feature 10 spindle 0.8kw
Feature 11 spindle motor 220v
Feature 12 spindle 2200w
Voltage 110V/220V
Feature 13 cnc spindle 1.5kw
Feature 14 80mm spindle mount
Feature 15 800w spindle
Feature 16 splinder cnc 800w
Speed 0-24000 R/min
Runout off less than 0.02mm
Suitable for wooden carving , drilling , engraving and milling machinery

Write a review

Note: HTML is not translated!
    Bad           Good

1.5KW 65MM ER11 Spindle Motor Spindel CNC 800W AC 220V 110V Air Cooling Spindle Engraving Milling Drilling Lathe Spindle Machine

  • Product Code: 1.5KW 65MM ER11 Spindle Motor Spindel CNC 800W AC 220V 110V Air
  • Availability: In Stock
  • $514.99

  • Ex Tax: $514.99

Available Options
